YH Series Automatic Textile Screen Printing Machine

设备运行视频（Device Running Video）：

布料印刷 FabricPrinting：

工厂布料印刷
Factory Fabric Printing

YH系列4色4烘干机10工位T恤丝网印刷机
YH Series 4 color 4 dryer 10 station t shirt screen printing mahcine

印刷带植绒 Flocking with Printing Bel：
植绒系统
flocking system

Basic introduction:

YHseries printing machine is the newest and mostadvancednew generationautomaticprinting equipment in China, which will bringyou highoutput andfastinvestment return. Its main features include:computermicro-processingsystem,accurate printing color setting accuracy,electricprinting head andpneumaticturntable lifting system, simple and fast netframeloading andunloading, independentscraping and printing ink recovery speedcanbe adjustedfreely, the machineframe can install flocking printing headandvivid touchscreen operationinterface.The YH series is available in4,6,8,10,12and 14colors, with a maximumprinting area of 500 x 700 mm. Allmodels can beprintedon t-shirts, sleeves, sheets andtextile bags.

Detailed characteristics:

1.Color touch screen operationinterface

2.The servo drive system can providehigh speed running speed while ensuringstable, durable and long service lifeof printing

3.Quick pneumatic platformreplacement function

4.The turntable can rotate clockwiseor counterclockwise

5.The net distance of all stations(the distance between the screen plate and thesubstrate surface) can beaccurately adjusted at the same time

6.The frame should be able toassemble oven, printing head and flocking printinghead as required

7.Manual tap jumping switch canavoid empty platform printing

8.Double shift function improvesprinting quality

9.The function of thick plateprinting and automatic plate-changing is optional

Details show:

Parameters:

型号 Model	YH-104/8	YH-156/10	YH-158/12
印色/工位 Print Color/Station	4/8	4-6/10	4-10/12
最大印刷面积 Maz. Image Area	500×700/mm/600×800/mm
台板大小 Pallet Size	600×800/mm/700×900/mm
网框大小 Frame Size	720×1050/mm/820×1150/mm
最大空气消耗 Max.Air Consumption	8P 24.71L/100mm (piston move)	8P 24.71L/100mm (piston move)	8P 30.44L/100mm (piston move)
最大产量 Max.Output	900pcs/h
功率 Power	2.9Kw	4.4Kw	4.4Kw
单个间歇式烘箱的功率 Each Dryer Power	13.5Kw
外形尺寸 Size	∮4800×1650 /mm	∮5500×1850 /mm	∮5500×1850 /mm
重量 Weight	2300Kg	3000Kg	3300Kg

型号 Model	YH-1510/14	YH-2012/18	YH-2016/18
印色/工位 Print Color/Station	4-12/14	4-12/16	4-16/18
最大印刷面积 Maz. Image Area	500×700/mm /600×800/mm	400×600/mm
台板大小 Pallet Size	600×800/mm /700×900/mm	500×700/mm
网框大小 Frame Size	720×1050/mm /820×1150/mm	620×950/mm
最大空气消耗 Max.Air Consumption	8P 31.51L/100mm (piston move)	8P 30.44L/100mm (piston move)	8P 34.91L/100mm (piston move)
最大产量 Max.Output	900pcs/h
功率 Power	4.4Kw	5.5Kw	5.5Kw
单个间歇式烘箱的功率 Each Dryer Power	13.5Kw
外形尺寸 Size	∮6000×1850 /mm	∮6400×1850 /mm	∮7000×2500 /mm
重量 Weight	3600Kg	4300Kg	5100Kg

Electrical equipment configuration:

Name	YH (Brand)
Touch Screen	DELTA colorful 10 inch
Power Switch	MEAN WELL
Servo Motor	YASKAWA
Transducer	DELTA 0.4KW/220V
Smatch Switch	MOELLER A22-FAK
AC Contactor	CHNT
Middle Relay	OMRON 24VDC
Proxity Switch	OMRON
Emergency Switch	SCHNEIDER BE102C
Switch With Lock	SCHNEIDER BE101C
Spin Switch	SCHNEIDER BE101C
Air Manometer	SMC
Special Cylinder	UNIQUC Bidirectional cylinder
Muffler	EASUN
Two-way	PNEUMAN
Two-way Valve	Mindman
Belt	Megadyne(Italy
